F20, the latest from Yamaha

By Redacción



Yamaha presents the latest outboard engine generation, the F20. In recent years, the larger F25 has proven to be one of Yamaha's most popular engines. Its solid and versatile reliability, low power consumption and easy operation have won over users.




F20, which shares many of the F25's key technologies, incorporates new features designed to make life, both in the water and on land. When it comes to carrying and storing, it is not only lightweight, but also has a comfortable design with a handle and padded protections in the perfect place. And maintenance is also easier. The easily accessible hose connector on the bottom allows salt and dirt to be discharged from the waterways without starting the engine: a simple and quick way to reduce corrosion and increase engine life and resale value.


F20, which shares many of the key technologies of the F25, incorporates novelties designed to make life, both in the water and on land.



Start smoothly, even in difficult conditions, thanks to the battery-free Electronic Fuel Injection (EFI) system, with a choice of electric, manual or mixed start. Smoother damping is also guaranteed thanks to the new, larger engine clamping system.
The electric start option is compatible with Yamaha's Digital Network instrumentation system, which includes the availability of stylish instruments that offer a selection of operating data and engine performance information, as well as increased accuracy and controllability.
With the multi-function handle you can change direction, drive and manoeuvre comfortably. The variable trawl speed system provides slower idling and allows you to control the trawl speed in 50 rpm increments, making it ideal for fishing. This practical advantage is standard on multi-function handle models and optional on F20 remote control models.




The variable trawl speed system provides slower idling and allows you to control the trawl speed in 50 rpm increments, making it ideal for fishing.


YAMAHA F20G
-Engine type: 4 stroke
-Valves: 4
-Displacement: 432 cc
-Propeller shaft power: 14.7 kW at 5500 rpm
-Full throttle operating range: 5000 - 6000 rpm
-Gear ratio: 2.08 (27/13)
-Fuel Induction System (EFI) - Ignition system: CDI
-Lubrication system: Wet sump
-Oil sump capacity: 1.1 litres
-Alternator: 12 V - 16 A with rectifier/regulator
-Manual (MH), manual/electric (WH) or electric (E, EP) starting system
-Control (options) Handle (MH, WH) or remote control (E, EP)
-Electrical inclination (EP) (optional) Manual inclination (MH, E, WH) Shallow water navigation Standard - 2 positions
-Recommended transom dimensions S: 429 mm /L: 556 mm
-Dry weight with propeller (kg) 56 (E)
-Available models: MH, WH, E, EP
www.yamaha-motor.eu/es
